Intended Use

For wet and dry constructions

For installation in partially high or high installations in front of walls

For installation in floor-to-ceiling installation walls

For installation in partially or floor-to-ceiling Geberit Duofix system walls

For installation in narrow spaces and niches

For wall-hung toilets with connection dimensions according to EN 33:2011

For wall-hung toilets with a distance of up to 62 cm

For 1 flush volume, 2 flush volumes, or start/stop flush

For floor thicknesses of 0-20 cm

Features

Self-supporting, powder-coated frame

Adjustable in width

Frame with drilled holes Ø 9 mm for mounting in wooden structures

Prepared frame for supports for toilet ceramics with a small support surface

Galvanized supports

Adjustable supports 0-20 cm

Non-slip supports

Rotatable support plates

Support plate depth suitable for installation in underground spaces 50 and UW 75 U profiles and in Geberit Duofix system profiles

Connection elbow for tool-free installation at various depths, adjustment range 45 mm

Attachment of the sound-insulated connection elbow

Concealed cistern with front operation

Concealed cistern insulated against fogging

Additional flush pre-set at the factory

Concealed cistern for tool-free installation and servicing

Water connection at the rear or top center

The cover for the rough installation of the service opening protects against moisture and contaminants

Cover for the rough installation of the service opening with the option to shorten it without tools

Pipe protection for the connecting pipe for the Geberit AquaClean shower toilet

With power supply attachment option

Technical specifications

Flow pressure: 10-1000 kPa

Maximum water temperature: 25 °C

Factory-set flush volume: 6 and 3 l

Large flush volume, adjustment range: 4.5 / 6 / 7.5 l

Small flush volume, setting range: 3-4 l

Scope of delivery

R 1/2" water connection, suitable for MF, with integrated angle valve and manual control dial

Cover for rough installation of the service opening

WC connection set, Ø 90 mm

90° PE-HD connection bend, ø 90 mm

PE-HD adapter, ø 90 / 110 mm

2 protective plugs

2 M12 threaded rods

Mounting material
